Coolant expansion tank
MAN Coolant expansion tank 50.06102-5000
Genuine MAN coolant expansion tank for D2868, D2862 and D3872 marine diesel engines, part of the engine's coolant de-aeration and cooling circuit.
Coolant expansion tank50.06102-5000
Engine modelD2868, D2862, D3872
Previous part no.-
Weight44.97 kg
Dimensions515 × 270 × 1005 mm
Country of originGermany
Warranty2 years
Genuine OEM · dispatched same day
Components
Parts contained in this heat exchanger assembly, per the MAN parts catalogue (reference 51.#0140-0945). This coolant expansion tank is position 1.
| Pos | Item number | Name / Remarks | Qty |
|---|---|---|---|
| 1 | 50.06102-5000 | coolant expansion tank | 1 |
| 2 | 51.06100-6227 | heat exchanger (05.12) | 1 |
| 2 | 51.06100-6233 | heat exchanger (31.17) | 1 |
| 2 | 51.06100-6250 | heat exchanger, 26 boards/plates | 1 |
| 3 | 51.06101-0093 | end plate front (05.14) | 1 |
| 3 | 51.06101-0120 | end plate front (36.16) | 1 |
| 3 | 51.06101-0142 | end plate front | 1 |
| 4 | 51.06101-0106 | centring pin (06.12) | 2 |
| 4 | 51.06101-0110 | centring pin | 2 |
| 5 | 51.90710-0240 | spacer 15X33X3-9SMNPB28K (01.19) | 2 |
| 5 | 51.90710-0615 | washer 15X33X3 | 2 |
| 6 | 06.03216-8505 | hex flange bolt M12X25-10.9-MAN183-B1 | 2 |
| 7 | 51.93030-0029 | bush 20,4X38X8/2,5X45-11SMPB30+C | 8 |
| 8 | 51.06101-5002 | bush (06.12) | 8 |
| 8 | 51.06101-5004 | bush | 8 |
| 9 | 06.01329-0013 | hexagon screw M16X100-A4-80 (33.10) | 8 |
| 9 | 06.01289-0322 | hexagon screw M16X100-8.8 (06.12) | 8 |
| 9 | 06.01289-0323 | hexagon screw M16X75-8.8 | 8 |
| 10 | 09.16012-0117 | assembly paste 100 G tube | NB |
| 11 | 06.15013-0416 | washer 16X30X3-200HV-MAN183-B1 | 8 |
| 12 | 51.06140-0194 | bracket surge tank (09.11) | 1 |
| 12 | 51.06140-0201 | bracket surge tank | 1 |
| 13 | 06.03216-8416 | hex flange bolt M10X90-10.9-MAN183-B1 | 4 |
| 14 | 06.03216-8423 | hex flange bolt M10X160-10.9-MAN183-B1 | 2 |
| 15 | 06.01014-7235 | hex shoulder stud M10X200-10.9-MAN183-B1 | 2 |
| 16 | 51.06140-0220 | bracket | 1 |
| 17 | 51.06140-0198 | bracket surge tank | 1 |
| 18 | 06.03216-8309 | hex flange bolt M8X45-10.9-MAN183-B1 | 8 |
| 19 | 51.93030-0306 | bush 9X18X15 | 8 |
| 20 | 06.08049-0045 | drain plug M14X1,5-ST-MAN183-B1 | 1 |
| 21 | 06.56631-0235 | seal 14,3X22X1,5-ST/FKM1-80 with elastomer lip | 1 |
| 22 | 51.90310-0259 | drain plug M32X1,5X22-ST-MAN183-B1 | 2 |
| 23 | 06.56631-0126 | seal 32,7X40X2,0-ST/FPM1-80 with elastomer lip | 2 |
| 24 | 51.97141-0025 | cover 1,4 BAR | 2 |
| 26 | 51.06106-0003 | sight glass | 2 |
| 27 | 51.06111-0031 | cover sight glass | 2 |
| 28 | 06.56936-2355 | O-ring 56,75X3,53N-FPM1-70-GN | 2 |
| 29 | 06.01283-4815 | hexagon screw M5X25-8.8-MAN183-B1 | 12 |
Specifications
| Part number | 50.06102-5000 |
| Part no. (other formats) | 50.06102.5000 · 50061025000 |
| Engine model |
|
| Previous part no. | - |
| Weight (kg) | 44.97 |
| Dimensions (mm) | 515 × 270 × 1005 |
| Country of origin | Germany |
| Warranty | 2 years |
| Availability | In stock |
